| Type | Model no. | Thickness | Fire class | Weight | Sound reduction |
Thermal transmittance |
|
C-511 | 25mm | B-0 | 7.3kg/㎡ | Dn,c,w 40 dB | 1.27kcal/㎡h℃ |
| C-511 (perforated) |
25mm | B-0 | 7.1kg/㎡ | - | 1.27kcal/㎡h℃ | |
| C-512 | 25mm | B-0 | 7.3kg/㎡ | Dn,c,w 43 dB | 1.27kcal/㎡h℃ | |
| C-512 (perforated) |
25mm | B-0 | 7.1kg/㎡ | - | 1.27kcal/㎡h℃ | |
|
C-513 | 75mm | B-15 | 11.3kg/㎡ | Dn,c,w 51 dB | 0.41kcal/㎡h℃ |
| C-513 (perforated) |
75mm | B-15 | 11.1kg/㎡ | - | 0.41kcal/㎡h℃ | |
| C-514 | 75mm | B-15 | 11.3kg/㎡ | Dn,c,w 45 dB | 0.41kcal/㎡h℃ | |
| C-514 (perforated) |
75mm | B-15 | 11.1kg/㎡ | - | 0.41kcal/㎡h℃ |
| Type | Model no. | Thickness | Fire class | Weight | Sound reduction |
Thermal transmittance |
|
C-613 | 25mm | B-0 | 7.7kg/㎡ | Dn,c,w 50 dB | 1.27kcal/㎡h℃ |
| C-615 | 50mm | B-15 | 10.2kg/㎡ | Dn,c,w 52 dB | 0.60kcal/㎡h℃ | |
|
C-643 | 45mm | B-0 | 8.3kg/㎡ | Dn,f,w 43 dB | 1.27kcal/㎡h℃ |
| C-643 (perforated) |
45mm | B-0 | 8.1kg/㎡ | - | 1.27kcal/㎡h℃ | |
| C-645 | 45mm | B-15 | 10.0kg/㎡ | Dn,f,w 45 dB | 0.75kcal/㎡h℃ | |
| C-645 (perforated) |
45mm | B-15 | 9.8kg/㎡ | - | 0.75kcal/㎡h℃ |
| Type | Model no. | Thickness | Fire class | Weight | Sound reduction |
Thermal transmittance |
|
CA452 | 23mm | C | 2.2kg/㎡ | - | 1.27kcal/㎡h℃ (w/Insulation) |
| CA452 (perforated) |
23mm | C | 1.8kg/㎡ | - | 1.27kcal/㎡h℃ (w/Insulation) |
| Type | Model no. | Thickness | Fire class | Weight | Sound reduction |
Thermal transmittance |
|
C452 | 27mm | B-0 | 7.1kg/㎡ | - | 1.27kcal/㎡h℃ |
| C452 (perforated) |
27mm | B-0 | 6.1kg/㎡ | NRC 0.75
(absorption) |
1.27kcal/㎡h℃ | |
|
C562 | 25mm | B-0 | 6.8kg/㎡ | Dn,c,w 40 dB | 1.27kcal/㎡h℃ |
| C562 (perforated) |
25mm | B-0 | 6.6kg/㎡ | NRC 0.75 (absorption) |
1.27kcal/㎡h℃ | |
| C563 | 50mm | B-15 | 9.1kg/㎡ | Dn,c,w 45 dB | 0.60kcal/㎡h℃ |
